Crowdsec Blocklists and Mikrotik Firewall
One question you always get when selfhosting is:
How do you secure your public facing services ?
The answer usually is in layers. One layer I use is the firewall on my Mirotik router that sits in front of all my selfhosted services. Another layer I use is Crowdsec which is an IDS/IPS that you can selfhost and is augmented by community blocklists. Today we will be setting both up so that the Mikrotik can use Crowdsec’s blocklists to secure my homelab network directly at the entrance.
CrowdSec is an open-source, collaborative security solution designed to detect and mitigate threats at scale. It functions as an Intrusion Prevention System (IPS) and Intrusion Detection System (IDS) by analyzing logs from various sources (such as firewalls, servers, and applications) to identify suspicious behavior.
We won’t be be covering the installation today but they do have a great Getting Started guide.
Setup
Install the Blocklist mirror bouncer
You can find out more about the Blocklist Mirror Bouncer at the official documentation site https://doc.crowdsec.net/docs/bouncers/blocklist-mirror.
Install the Blacklist mirror bouncer on your crowdsec host.
sudo apt install crowdsec-blocklist-mirror
# Already installed in my case
Reading package lists... Done
Building dependency tree... Done
Reading state information... Done
crowdsec-blocklist-mirror is already the newest version (0.0.4).
0 upgraded, 0 newly installed, 0 to remove and 18 not upgraded.We can then check that the bouncer has been installed and is found by Crowdsec
sudo cscli bouncers list
─────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
Name IP Address Valid Last API pull Type Version Auth Type
─────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
cs-firewall-bouncer 127.0.0.1 ✔️ 2025-02-23T12:46:53Z crowdsec-firewall-bouncer v0.0.31-debian-pragmatic-amd64-4b99c161b2c1837d76c5fa89e1df83803dfbcc87 api-key
cs-blocklist-mirror-1738504976 127.0.0.1 ✔️ 2025-02-23T12:46:46Z crowdsec-blocklist-mirror v0.0.4-debian-pragmatic-amd64-cb1396da47b875b74486803272c91a76ef77ac7f api-key
─────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────This command lists all the bouncers installed on your system. You should have a similar output.
Now we need to edit the bouncers configuration in /etc/crowdsec/bouncers/crowdsec-blocklist-mirror.yaml
sudo vi /etc/crowdsec/bouncers/crowdsec-blocklist-mirror.yamlThe first setting we want to change is format: mikrotik this sets the output format to be compatible with mikrotik cli. Finally we need to change the listen_uri: to match our local ip and the port we would like the bouncer to be available on.
Once all the changes are made your crowdsec-blocklist-mirror.yaml should look like below
config_version: v1.0
crowdsec_config:
lapi_key: <API KEY>
lapi_url: http://127.0.0.1:8080
update_frequency: 10s
include_scenarios_containing: []
exclude_scenarios_containing: []
only_include_decisions_from: []
insecure_skip_verify: false
blocklists:
- format: mikrotik # Supported formats are either "plain_text" or "mikrotik"
endpoint: /security/blocklist
authentication:
type: none # Supported types are either "none", "ip_based" or "basic"
user:
password:
trusted_ips: # IP ranges, or IPs that don't require auth to access this blocklist
- 127.0.0.1
- ::1
listen_uri: Server_IP:41412 # Add your server's IP
tls:
cert_file:
key_file:
metrics:
enabled: true
endpoint: /metrics
# logging configuration
log_media: file
log_dir: /var/log/
log_level: info
log_max_size: 40
log_max_age: 30
log_max_backups: 3
compress_logs: true
# enable access log of the HTTP server
enable_access_logs: trueWe can then restart the blocklist mirror bouncer and check that the service is running
sudo systemctl restart crowdsec-blocklist-mirrorsudo systemctl status crowdsec-blocklist-mirror
● crowdsec-blocklist-mirror.service - CrowdSec Blocklist Mirror
Loaded: loaded (/etc/systemd/system/crowdsec-blocklist-mirror.service; enabled; vendor preset: enabled)
Active: active (running) since Sun 2025-02-23 13:58:54 CET; 58s ago
Process: 2578810 ExecStartPre=/usr/bin/crowdsec-blocklist-mirror -c /etc/crowdsec/bouncers/crowdsec-blocklist-mirror.yaml -t (code=exited, status=0/SUCCESS)
Main PID: 2578818 (crowdsec-blockl)
Tasks: 13 (limit: 11923)
Memory: 37.5M
CPU: 422ms
CGroup: /system.slice/crowdsec-blocklist-mirror.service
└─2578818 /usr/bin/crowdsec-blocklist-mirror -c /etc/crowdsec/bouncers/crowdsec-blocklist-mirror.yaml
Feb 23 13:58:54 web01 systemd[1]: Starting CrowdSec Blocklist Mirror...
Feb 23 13:58:54 web01 systemd[1]: Started CrowdSec Blocklist Mirror.Our list published by the blocklist mirror bouncer is now available at http://server_IP:41412/security/blocklist and if we visit the url in a browser or use curl we can see the list.
curl http://server_IP:41412/security/blocklist/ip/firewall/address-list/remove [ find where list="CrowdSec" ];
:global CrowdSecAddIP;
:set CrowdSecAddIP do={
:do { /ip/firewall/address-list/add list=CrowdSec address=$1 comment="$2" timeout=$3; } on-error={ }
}
/ipv6/firewall/address-list/remove [ find where list="CrowdSec" ];
:global CrowdSecAddIPv6;
:set CrowdSecAddIPv6 do={
:do { /ipv6/firewall/address-list/add list=CrowdSec address=$1 comment="$2" timeout=$3; } on-error={ }
}
$CrowdSecAddIP "1.11.89.43" "crowdsecurity/ssh-slow-bf" "155h1m52s"
$CrowdSecAddIP "1.116.238.156" "crowdsecurity/http-probing" "161h1m51s"
$CrowdSecAddIP "1.117.113.68" "crowdsecurity/ssh-slow-bf" "155h1m52s"
$CrowdSecAddIP "1.117.37.207" "crowdsecurity/http-bad-user-agent" "154h1m52s"
$CrowdSecAddIP "1.117.73.212" "crowdsecurity/http-bad-user-agent" "136h33m13s"
$CrowdSecAddIP "1.12.48.131" "crowdsecurity/http-probing" "164h1m51s"
$CrowdSecAddIP "1.12.55.42" "crowdsecurity/http-probing" "165h1m51s"
$CrowdSecAddIP "1.14.105.106" "crowdsecurity/http-probing" "165h1m51s"
...Notice how it is formatted to be pasted into the Mikrotik CLI. We could stop here and just past the list to the CLI and setup a block rule. But what about updates as the list is regularly updated?
Mikrotik
Note: we are using the Mikrotik CLI to set this up but you can also use Winbox if you wanted to.
We now need a script to update the blocklist on our Mikrotik and a block rule to use it.
To create a script we are going to use Mikrotik’s scripting language.
We can add our script using the following command while making sure to replace server_IP with the IP address of our mirror bouncer.
/system script
add dont-require-permissions=no name=crowdsec_import policy=\
ftp,reboot,read,write,policy,test,password,sniff,sensitive,romon source=":local name \"[crowdsec]\"\
\n:local url \"http://server_IP:41412/security/blocklist\"\
\n:local fileName \"blocklist.rsc\"\
\n:log info \"\$name fetch blocklist from \$url\"\
\n/tool fetch url=\"\$url\" mode=http dst-path=\$fileName\
\n:if ([:len [/file find name=\$fileName]] > 0) do={\
\n :log info \"\$name import;start\"\
\n /import file-name=\$fileName\
\n :log info \"\$name import:done\"\
\n} else={\
\n :log error \"\$name failed to fetch the blocklist\"\
\n}"Next we need to add a scheduled task to run the script and update the list, we run it every 15 minutes.
/system scheduler
add interval=15m name=schedule1 on-event="system/script/run crowdsec_import"Once our script has run, we can check if our address list has been populated with IPs to block.
/ip/firewall/address-list/print where list=CrowdSec
Flags: X - disabled, D - dynamic
# LIST ADDRESS CREATION-TIME TIMEOUT
14 D ;;; http:scan
CrowdSec 1.12.48.131 2025-04-24 11:09:16 3h52m57s
15 D ;;; http:scan
CrowdSec 1.12.55.42 2025-04-24 11:09:16 4h52m57s
16 D ;;; http:scan
CrowdSec 1.14.105.106 2025-04-24 11:09:16 5h52m57s
17 D ;;; http:scan
CrowdSec 1.14.14.169 2025-04-24 11:09:16 5h52m57s
18 D ;;; http:scan
CrowdSec 1.14.61.226 2025-04-24 11:09:16 3h52m57s
19 D ;;; http:scan
CrowdSec 1.14.64.103 2025-04-24 11:09:16 2d16h52m57s
20 D ;;; http:scan
CrowdSec 1.14.66.207 2025-04-24 11:09:16 52m57s
21 D ;;; http:scan
CrowdSec 1.14.73.93 2025-04-24 11:09:16 5h52m57s
22 D ;;; http:scan
CrowdSec 1.14.77.81 2025-04-24 11:09:16 3h52m57s
23 D ;;; http:scan
CrowdSec 1.14.92.22 2025-04-24 11:09:16 3h52m57s
24 D ;;; http:scan
CrowdSec 1.14.93.149 2025-04-24 11:09:16 5h52m57s
25 D ;;; http:scan
CrowdSec 1.14.94.175 2025-04-24 11:09:16 5h52m57s
26 D ;;; http:scan
CrowdSec 1.14.96.114 2025-04-24 11:09:16 4h52m57s
27 D ;;; http:scan
-- [Q quit|D dump|down]We finally need to add a firewall rule to actually block any IPs in our list. We add two rules, one for the forward chain and another for the input chain. We add these rules at the top of our list as the firewall rules a processed in top down order.
/ip firewall filter
add action=drop chain=forward comment="Drop from Crowdsec Lists" src-address-list=CrowdSec
add action=drop chain=input comment="Drop from Crowdsec Lists" src-address-list=CrowdSecOnce our rule has been added we can see traffic being blocked.
# CHAIN ACTION BYTES PACKETS
;;; Drop from Crowdsec Lists
0 forward drop 1 524 773 25 568
;;; Drop from Crowdsec Lists
1 input drop 339 980 6 586Now the firewall on our Mikrotik router is using address lists provided by our Crowdsec bouncer to block suspicious requests.
End
This just a small taste of what we can do with CrowdSec. CrowdSec can do a lot more, like acting as a Web Application Filter and virtual patching in front of your websites, scanning system logs for suspicious behaviors, and then block those behaviors. I might write a poste about its other features in the future.
